0678005001 COUNTRY OF ORIGIN
|
0678005001 PARAMETRIC INFO
|
0678005001 PACKAGE INFO
|
0678005001 MANUFACTURING INFO
|
0678005001 PACKAGING INFO
|
|
COUNTRY OF ORIGIN
|
India
|
Malaysia
|
|
PARAMETRIC INFO
|
| Type |
SATA |
| Gender |
PL |
| Number of Contacts |
7 |
| Termination Method |
Solder |
| Number of Ports |
1 |
| Maximum Current Rating (A) |
1.5/Contact |
| Maximum Voltage Rating |
15VAC |
| Housing Material |
Thermoplastic |
| Contact Material |
Brass |
| Contact Plating |
Gold Over Nickel |
| Operating Temperature (°C) |
-35 to 85 |
| Minimum Operating Temperature (°C) |
-35 |
| Maximum Operating Temperature (°C) |
85 |
| Mating Cycle (Cycles) |
50 |
|
|
PACKAGE INFO
|
| Terminal Pitch (mm) |
1.27 |
| Body Orientation |
Straight |
| Mounting |
Surface Mount |
| Number of Terminals |
7 |
| Product Length (mm) |
16.9 |
| Product Depth (mm) |
6.45 |
| Product Height (mm) |
8.4 |
| Product Weight (g) |
0.912 |
|
|
MANUFACTURING INFO
|
| MSL |
N/A |
| Maximum Reflow Temperature (°C) |
N/A |
| Reflow Solder Time (Sec) |
N/A |
| Number of Reflow Cycle |
N/A |
| Standard |
N/A |
| Reflow Temp. Source |
Link to Datasheet |
| Maximum Wave Temperature (°C) |
N/R |
| Wave Solder Time (Sec) |
N/R |
| Lead Finish(Plating) |
Sn |
| Under Plating Material |
N/A |
| Terminal Base Material |
Brass |
| Number of Wave Cycles |
N/R |
|
|
PACKAGING INFO
|
|
|
