08SUR-32S PARAMETRIC INFO
|
08SUR-32S PACKAGE INFO
|
08SUR-32S MANUFACTURING INFO
|
08SUR-32S PACKAGING INFO
|
|
PARAMETRIC INFO
|
| Type |
IDC Connector |
| Gender |
RCP |
| Number of Contacts |
8 |
| Termination Method |
IDT |
| Maximum Current Rating (A) |
0.5 |
| Maximum Voltage Rating |
30VDC |
| Housing Material |
Polyamide |
| Housing Color |
Natural |
| Contact Material |
Copper Alloy |
| Contact Plating |
Tin |
| Number of Rows |
1 |
| Maximum Contact Resistance (mOhm) |
40 |
| Wire Size (AWG) |
32-36 |
| Insulation Resistance (MOhm) |
100 |
| Operating Temperature (°C) |
-25 to 85 |
| Minimum Operating Temperature (°C) |
-25 |
| Maximum Operating Temperature (°C) |
85 |
|
|
PACKAGE INFO
|
| Terminal Pitch (mm) |
0.8 |
| Body Orientation |
Straight |
| Mounting |
Cable Mount |
| Product Length (mm) |
7.2 |
| Product Depth (mm) |
2.9 |
| Product Height (mm) |
1.65 |
|
|
MANUFACTURING INFO
|
| MSL |
N/R |
| Maximum Reflow Temperature (°C) |
N/R |
| Reflow Solder Time (Sec) |
N/R |
| Maximum Wave Temperature (°C) |
N/A |
| Wave Solder Time (Sec) |
N/A |
| Wave Temp. Source |
Link to Datasheet |
| Lead Finish(Plating) |
N/A |
| Under Plating Material |
N/A |
| Terminal Base Material |
Cu Alloy |
|
| |
PACKAGING INFO
|
|
|
| |
