1-927771-1 COUNTRY OF ORIGIN
|
1-927771-1 PARAMETRIC INFO
|
1-927771-1 PACKAGE INFO
|
1-927771-1 MANUFACTURING INFO
|
| 1-927771-1 PACKAGING INFO |
|
COUNTRY OF ORIGIN
|
China
|
Czechia
|
Germany
|
Belgium
|
Spain
|
|
PARAMETRIC INFO
|
| Series Name |
Junior-Power-Timer |
| Connector Type |
Connector Headers and PCB Receptacles |
| Gender |
SKT |
| Termination Method |
Crimp |
| Contact Type |
Signal |
| Maximum Current Rating (A) |
30 |
| Contact Material |
Copper Iron |
| Contact Plating |
Gold Over Nickel |
| Shielded |
No |
| Wire Size (AWG) |
17-20 |
|
|
PACKAGE INFO
|
| Body Orientation |
Straight |
| Mounting |
Cable Mount |
| Product Length (mm) |
18.8 |
| Product Depth (mm) |
3.6 |
| Product Height (mm) |
4.15 |
|
|
MANUFACTURING INFO
|
| MSL |
N/R |
| Maximum Reflow Temperature (°C) |
N/R |
| Reflow Solder Time (Sec) |
N/R |
| Reflow Temp. Source |
Link to Datasheet |
| Maximum Wave Temperature (°C) |
N/R |
| Wave Solder Time (Sec) |
N/R |
| Wave Temp. Source |
Link to Datasheet |
| Lead Finish(Plating) |
N/A |
| Under Plating Material |
N/A |
| Terminal Base Material |
CuFe |
|
|
PACKAGING INFO
|
| Packaging |
Tape and Reel |
| Quantity Of Packaging |
4000 |
|
|
