| CATALOG |
| 102387-4 COUNTRY OF ORIGIN |
102387-4 PARAMETRIC INFO
|
102387-4 PACKAGE INFO
|
102387-4 MANUFACTURING INFO
|
102387-4 PACKAGING INFO
|
102387-4 EACD MODELS
|
|
| COUNTRY OF ORIGIN |
| Switzerland |
| China |
| Mexico |
| United States of America |
|
PARAMETRIC INFO
|
| Type |
Housing |
| Gender |
RCP |
| Number of Contacts |
20 |
| Termination Method |
Crimp |
| Maximum Current Rating (A) |
3/Contact |
| Maximum Voltage Rating |
250VAC |
| Housing Material |
Thermoplastic |
| Housing Color |
Black |
| Number of Rows |
2 |
| Wire Size (AWG) |
22-30 |
| Insulation Resistance (MOhm) |
5000 |
| Operating Temperature (°C) |
-65 to 105 |
| Minimum Operating Temperature (°C) |
-65 |
| Maximum Operating Temperature (°C) |
105 |
|
|
PACKAGE INFO
|
| Terminal Pitch (mm) |
2.54 |
| Body Orientation |
Straight |
| Mounting |
Cable Mount |
| Product Length (mm) |
29.97 |
| Product Depth (mm) |
7.23 |
| Product Height (mm) |
15.24 |
| Product Weight (g) |
N/A |
|
| |
MANUFACTURING INFO
|
| MSL |
N/R |
| Maximum Reflow Temperature (°C) |
N/R |
| Reflow Solder Time (Sec) |
N/R |
| Reflow Temp. Source |
Link to Datasheet |
| Maximum Wave Temperature (°C) |
N/R |
| Wave Solder Time (Sec) |
N/R |
| Wave Temp. Source |
Link to Datasheet |
| Lead Finish(Plating) |
N/R |
| Under Plating Material |
N/R |
| Terminal Base Material |
N/R |
|
|
PACKAGING INFO
|
| Packaging |
Package |
| Quantity Of Packaging |
500 |
|
|
ECAD MODELS
|
|
|
