COUNTRY OF ORIGIN
|
Taiwan (Province of China)
|
|
PARAMETRIC INFO
|
| Type |
Crystal |
| Standard Frequency (MHz) |
25 |
| Frequency Tolerance (ppm) |
±30 |
| Frequency Stability (ppm) |
±30 |
| Load Capacitance (pF) |
12 |
| Mode of Oscillation |
Fundamental |
| Series Resistance (Ohm) |
60 |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
85 |
| Frequency Aging (ppm/Year) |
±2 (1st) |
|
|
PACKAGE INFO
|
| Supplier Package |
SMD |
| Pin Count |
4 |
| PCB |
4 |
| Tab |
N/R |
| Package Length (mm) |
3.2 |
| Package Width (mm) |
2.5 |
| Package Height (mm) |
0.7 |
| Package Diameter (mm) |
N/R |
| Seated Plane Height (mm) |
0.7 |
| Mounting |
Surface Mount |
| Package Description |
Surface Mount Device |
| Package Family Name |
SMD |
| Package Outline |
Link to Datasheet |
|
|
MANUFACTURING INFO
|
|
|
PACKAGING INFO
|
| Packaging |
Tape and Reel |
| Quantity Of Packaging |
1000 |
|
|
