| CATALOG |
1318750-2 COUNTRY OF ORIGIN
|
1318750-2 PARAMETRIC INFO
|
1318750-2 PACKAGE INFO
|
1318750-2 MANUFACTURING INFO
|
1318750-2 PACKAGING INFO
|
|
COUNTRY OF ORIGIN
|
United States of America
|
Japan
|
|
PARAMETRIC INFO
|
| Type |
Wire to Board |
| Gender |
M |
| Number of Contacts |
50 |
| Termination Method |
Solder |
| Maximum Voltage Rating |
12VDC |
| Housing Material |
Polybutylene Terephthalate |
| Housing Color |
Natural |
| Contact Material |
Brass |
| Contact Plating |
Pre-Tin |
| Number of Rows |
3 |
| Row Spacing (mm) |
3/0.5 |
| Operating Temperature (°C) |
-30 to 105 |
| Minimum Operating Temperature (°C) |
-30 |
| Maximum Operating Temperature (°C) |
105 |
|
|
PACKAGE INFO
|
| Terminal Pitch (mm) |
2.2 |
| Body Orientation |
Right Angle |
| Mounting |
Through Hole |
| Product Length (mm) |
56.5 |
| Product Depth (mm) |
33.4 |
| Product Height (mm) |
20.6 |
|
|
MANUFACTURING INFO
|
| MSL |
N/R |
| Maximum Reflow Temperature (°C) |
N/R |
| Reflow Solder Time (Sec) |
N/R |
| Maximum Wave Temperature (°C) |
240 |
| Wave Solder Time (Sec) |
N/A |
| Wave Temp. Source |
Link to Datasheet |
| Lead Finish(Plating) |
N/A |
| Under Plating Material |
N/A |
| Terminal Base Material |
Brass |
|
|
PACKAGING INFO
|
| Packaging |
Tube |
| Quantity Of Packaging |
9 |
| Packaging Document |
Link to Datasheet |
|
|
