| CATALOG |
14250R-300 COUNTRY OF ORIGIN
|
| 14250R-300 LIFECYCLE |
14250R-300 PARAMETRIC INFO
|
14250R-300 PACKAGE INFO
|
14250R-300 MANUFACTURING INFO
|
|
COUNTRY OF ORIGIN
|
| Taiwan (Province of China) |
|
| LIFECYCLE |
Obsolete
Oct 22,2022 |
|
PARAMETRIC INFO
|
| Type |
Free Topology Transceiver |
| Number of Transmitters |
1 |
| Number of Receivers |
1 |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
85 |
| Power Supply Type |
Single |
| Typical Single Supply Voltage (V) |
5 |
| Minimum Single Supply Voltage (V) |
4.75 |
| Maximum Single Supply Voltage (V) |
5.25 |
| Maximum Supply Current (mA) |
75 |
|
|
PACKAGE INFO
|
| Supplier Package |
SMT |
| Pin Count |
4 |
| PCB |
4 |
| Tab |
N/R |
| Package Length (mm) |
16.77 |
| Package Width (mm) |
14.22 |
| Package Height (mm) |
8.18 |
| Package Diameter (mm) |
N/R |
| Mounting |
Surface Mount |
| Package Description |
Surface Mount Device |
| Package Family Name |
SMD |
| Jedec |
N/A |
|
|
MANUFACTURING INFO
|
| MSL |
N/A |
| Maximum Reflow Temperature (°C) |
260 |
| Reflow Solder Time (Sec) |
20 to 40 |
| Maximum Wave Temperature (°C) |
N/R |
| Wave Solder Time (Sec) |
N/R |
| Lead Finish(Plating) |
N/A |
| Under Plating Material |
N/A |
| Terminal Base Material |
N/A |
|
| |
