| CATALOG |
170M5812D COUNTRY OF ORIGIN
|
170M5812D PARAMETRIC INFO
|
170M5812D PACKAGE INFO
|
170M5812D MANUFACTURING INFO
|
|
COUNTRY OF ORIGIN
|
United States of America
|
|
PARAMETRIC INFO
|
| Typical Melting I2t (A²s) |
41000(Min) |
| Type |
Square Body |
| Current Rating (A) |
630 |
| Voltage Rating (V) |
690 |
| Maximum AC Voltage Rating (V) |
690 |
| Application |
Motor Circuit |
| Maximum Power Dissipation (W) |
42 |
| Fuse Size (mm) |
68 X 72 X 54 |
|
|
PACKAGE INFO
|
| Mounting |
Holder |
| Package/Case |
N/A |
| Number of Terminals |
2 |
| Terminal Pitch (mm) |
N/R |
| Product Length (mm) |
68 |
| Product Depth (mm) |
72 |
| Product Height (mm) |
54 |
| Product Diameter (mm) |
N/R |
| Seated Plane Height (mm) |
N/R |
| Termination Style |
Flat |
|
|
MANUFACTURING INFO
|
| MSL |
N/R |
| Maximum Reflow Temperature (°C) |
N/R |
| Reflow Solder Time (Sec) |
N/R |
| Reflow Temp. Source |
Link to Datasheet |
| Maximum Wave Temperature (°C) |
N/A |
| Wave Solder Time (Sec) |
N/A |
| Wave Temp. Source |
Link to Datasheet |
| Lead Finish(Plating) |
N/A |
| Under Plating Material |
N/A |
| Terminal Base Material |
N/A |
|
|
