1734099-5 COUNTRY OF ORIGIN
|
1734099-5 PARAMETRIC INFO
|
1734099-5 PACKAGE INFO
|
1734099-5 MANUFACTURING INFO
|
1734099-5 PACKAGING INFO
|
|
COUNTRY OF ORIGIN
|
China
|
|
PARAMETRIC INFO
|
| Type |
High Density |
| Gender |
PL |
| Number of Contacts |
50 |
| Termination Method |
Solder |
| Number of Ports |
1 |
| Maximum Current Rating (A) |
1/Contact |
| Maximum Voltage Rating |
12VDC |
| Housing Material |
Liquid Crystal Polymer |
| Contact Material |
Phosphor Bronze |
| Contact Plating |
Gold Over Palladium Nickel |
| Insulation Resistance (MOhm) |
4 |
| Maximum Contact Resistance (mOhm) |
15 |
| Operating Temperature (°C) |
-35 to 85 |
| Minimum Operating Temperature (°C) |
-35 |
| Maximum Operating Temperature (°C) |
85 |
| Mating Cycle (Cycles) |
500 |
| Maximum Terminal Width (mm) |
0.5(Typ) |
|
|
PACKAGE INFO
|
| Terminal Pitch (mm) |
1.27 |
| Body Orientation |
Right Angle |
| Mounting |
Through Hole |
| Number of Terminals |
50 |
| Product Length (mm) |
41.68 |
| Product Depth (mm) |
17.46 |
| Product Height (mm) |
7.5 |
| Length Tolerance (mm) |
±0.25 |
| Depth Tolerance (mm) |
±0.15 |
| Height Tolerance (mm) |
±0.1 |
| Product Weight (g) |
N/A |
|
|
MANUFACTURING INFO
|
| MSL |
N/R |
| Maximum Reflow Temperature (°C) |
N/R |
| Reflow Solder Time (Sec) |
N/R |
| Number of Reflow Cycle |
N/R |
| Maximum Wave Temperature (°C) |
265 |
| Wave Solder Time (Sec) |
N/A |
| Lead Finish(Plating) |
Sn |
| Under Plating Material |
N/A |
| Terminal Base Material |
Phosphor-Bronze |
|
|
PACKAGING INFO
|
| Packaging |
Tray |
| Quantity Of Packaging |
35 |
|
|
