| CATALOG |
175448-6 COUNTRY OF ORIGIN
|
175448-6 PARAMETRIC INFO
|
175448-6 PACKAGE INFO
|
175448-6 MANUFACTURING INFO
|
175448-6 PACKAGING INFO
|
|
COUNTRY OF ORIGIN
|
China
|
Japan
|
United States of America
|
|
PARAMETRIC INFO
|
| Type |
Multilock Connector |
| Gender |
Tab |
| Number of Contacts |
54 |
| Termination Method |
Solder |
| Maximum Voltage Rating |
12VDC |
| Housing Material |
Polybutylene Terephthalate |
| Housing Color |
Gray |
| Contact Material |
Brass |
| Contact Plating |
Tin/Gold |
| Number of Rows |
2 |
| Row Spacing (mm) |
5.2 |
| Operating Temperature (°C) |
-30 to 105 |
| Minimum Operating Temperature (°C) |
-30 |
| Maximum Operating Temperature (°C) |
105 |
|
|
PACKAGE INFO
|
| Terminal Pitch (mm) |
N/A |
| Body Orientation |
Right Angle |
| Mounting |
Through Hole |
| Product Length (mm) |
95.8 |
| Product Depth (mm) |
25.8 |
| Product Height (mm) |
21.9 |
|
|
MANUFACTURING INFO
|
| MSL |
N/R |
| Maximum Reflow Temperature (°C) |
N/R |
| Reflow Solder Time (Sec) |
N/R |
| Maximum Wave Temperature (°C) |
240 |
| Wave Solder Time (Sec) |
N/A |
| Wave Temp. Source |
Link to Datasheet |
| Lead Finish(Plating) |
N/A |
| Under Plating Material |
N/A |
| Terminal Base Material |
Brass |
|
|
PACKAGING INFO
|
| Packaging |
Tube |
| Quantity Of Packaging |
5 |
| Packaging Document |
Link to Datasheet |
|
|
|
