COUNTRY OF ORIGIN
|
Germany
|
|
PARAMETRIC INFO
|
| Type |
Terminal Block |
| Gender |
F |
| Number of Contacts |
2 |
| Termination Method |
Screw |
| Maximum Current Rating (A) |
12 |
| Number of Circuits |
2 |
| Maximum Voltage Rating |
320V |
| Wire Size (AWG) |
12-24 |
| Number of Rows |
1 |
| Contact Material |
Copper Alloy |
| Contact Plating |
Tin |
| Housing Material |
Polyamide |
| Housing Color |
Green |
| Insulation Resistance (MOhm) |
5 |
| Operating Temperature (°C) |
-40 to 100 |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
100 |
| Minimum Storage Temperature (°C) |
-40 |
| Maximum Storage Temperature (°C) |
70 |
|
|
PACKAGE INFO
|
| Terminal Pitch (mm) |
5.08 |
| Body Orientation |
Right Angle |
| Mounting |
Cable Mount |
| Product Length (mm) |
10.16 |
| Product Depth (mm) |
18.3 |
| Product Height (mm) |
15 |
| Length Tolerance (mm) |
±0.15 |
| Depth Tolerance (mm) |
±0.2 |
| Height Tolerance (mm) |
±0.15 |
| Product Weight (g) |
3.479 |
|
|
MANUFACTURING INFO
|
| MSL |
N/R |
| Maximum Reflow Temperature (°C) |
N/R |
| Reflow Solder Time (Sec) |
N/R |
| Number of Reflow Cycle |
N/R |
| Standard |
N/R |
| Maximum Wave Temperature (°C) |
N/R |
| Wave Solder Time (Sec) |
N/R |
| Lead Finish(Plating) |
Bright Sn |
| Under Plating Material |
N/A |
| Terminal Base Material |
Cu Alloy |
| Number of Wave Cycles |
N/R |
|
|
PACKAGING INFO
|
| Packaging Document |
Link to Datasheet |
|
|
