2-1703930-1 COUNTRY OF ORIGIN
|
2-1703930-1 PARAMETRIC INFO
|
2-1703930-1 PACKAGE INFO
|
2-1703930-1 MANUFACTURING INFO
|
2-1703930-1 PACKAGING INFO
|
2-1703930-1 ECAD MODELS
|
|
COUNTRY OF ORIGIN
|
Switzerland
|
Germany
|
United States of America
|
China
|
Czechia
|
|
PARAMETRIC INFO
|
| Connector Type |
Connector Headers and PCB Receptacles |
| Gender |
SKT |
| Termination Method |
Crimp |
| Contact Type |
Signal |
| Maximum Current Rating (A) |
6 |
| Contact Material |
Bronze |
| Contact Plating |
Tin |
| Shielded |
No |
| Wire Size (AWG) |
22-24 |
|
|
PACKAGE INFO
|
| Body Orientation |
Straight |
| Mounting |
Cable Mount |
| Product Length (mm) |
13.9 |
| Product Depth (mm) |
1.9 |
| Product Height (mm) |
1.8 |
|
|
MANUFACTURING INFO
|
| MSL |
N/R |
| Maximum Reflow Temperature (°C) |
N/R |
| Reflow Solder Time (Sec) |
N/R |
| Maximum Wave Temperature (°C) |
N/R |
| Wave Solder Time (Sec) |
N/R |
| Lead Finish(Plating) |
Sn |
| Under Plating Material |
N/A |
| Terminal Base Material |
CuSn |
|
|
PACKAGING INFO
|
| Packaging |
Tape and Reel |
| Quantity Of Packaging |
17000 |
|
|
ECAD MODELS
|
|
|
