| Logic Family |
VHC |
| Logic Function |
AND |
| Number of Element Inputs |
2-IN |
| Number of Element Outputs |
1 |
| Maximum Supply Current (mA) |
50 |
| Number of Elements per Chip |
1 |
| Number of Output Enables per Element |
0 |
| Number of Selection Inputs per Element |
0 |
| Process Technology |
CMOS |
| Minimum Operating Supply Voltage (V) |
2 |
| Maximum Operating Supply Voltage (V) |
5.5 |
| Typical Operating Supply Voltage (V) |
2.5|3.3|5 |
| Maximum High Level Output Current (mA) |
-8 |
| Maximum Low Level Output Current (mA) |
8 |
| Minimum Operating Temperature (°C) |
-55 |
| Maximum Operating Temperature (°C) |
125 |
| Supplier Temperature Grade |
Automotive |
| Minimum Storage Temperature (°C) |
-65 |
| Maximum Storage Temperature (°C) |
150 |
| Maximum Propagation Delay Time @ Maximum CL (ns) |
12.3@3V to 3.6V|7.9@4.5V to 5.5V |
| Absolute Propagation Delay Time (ns) |
16.5 |
| Propagation Delay Test Condition (pF) |
50 |
| Maximum Quiescent Current (uA) |
1 |
