| Type |
Wire to Board |
| Gender |
HDR |
| Number of Contacts |
4Power |
| Termination Method |
Solder |
| Tradename |
Micro-Fit 3.0 |
| Maximum Current Rating (A) |
8.5/Contact |
| Maximum Voltage Rating |
600V |
| Housing Material |
Glass Filled Liquid Crystal Polymer |
| Number of Termination Rows |
2 |
| Housing Color |
Black |
| Contact Material |
Brass Alloy |
| Contact Plating |
Matte Tin Over Nickel |
| Number of Rows |
2 |
| Row Spacing (mm) |
3 |
| Maximum Contact Resistance (mOhm) |
10 |
| Polarization Type |
Center Key |
| Wire Size (AWG) |
18-30 |
| Insulation Resistance (MOhm) |
1000 |
| Operating Temperature (°C) |
-40 to 105 |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
105 |
| Mating Cycle (Cycles) |
30 |
| Maximum Terminal Width (mm) |
0.64(Typ) |
| Maximum Terminal Coplanarity (mm) |
0.15 |
| Minimum Storage Temperature (°C) |
-40 |
| Maximum Storage Temperature (°C) |
105 |
| Mounting Styles |
Solder Tab |
| Contact Plating Thickness |
(1.52/1.27)um |
| Terminal Plating Thickness |
(1.52/1.27)um |
| Tail Shape |
Square |
| Mounting Ears |
No |
