| CATALOG |
51004-0200 COUNTRY OF ORIGIN
|
| 51004-0200 LIFECYCLE |
51004-0200 PARAMETRIC INFO
|
51004-0200 PACKAGE INFO
|
51004-0200 MANUFACTURING INFO
|
51004-0200 PACKAGING INFO
|
|
COUNTRY OF ORIGIN
|
China
|
Korea (Republic of)
|
Mexico
|
Taiwan (Province of China)
|
United States of America
|
Japan
|
Hong Kong
|
|
| LIFECYCLE |
Obsolete
Jun 21,2021 |
|
PARAMETRIC INFO
|
| Type |
Housing |
| Gender |
RCP |
| Number of Contacts |
2 |
| Termination Method |
Crimp |
| Tradename |
MicroBlade™ |
| Maximum Current Rating (A) |
2/Contact |
| Maximum Voltage Rating |
125VDC|125VAC |
| Housing Material |
Polybutylene Terephthalate |
| Housing Color |
Natural |
| Number of Rows |
1 |
| Insulation Resistance (MOhm) |
1000 |
| Operating Temperature (°C) |
-20 to 85 |
| Minimum Operating Temperature (°C) |
-20 |
| Maximum Operating Temperature (°C) |
85 |
|
|
PACKAGE INFO
|
| Terminal Pitch (mm) |
2 |
| Body Orientation |
Straight |
| Mounting |
Cable Mount |
| Product Length (mm) |
6 |
| Product Depth (mm) |
N/A |
| Product Height (mm) |
5.8 |
| Product Weight (g) |
0.0721 |
|
|
MANUFACTURING INFO
|
| MSL |
N/R |
| Maximum Reflow Temperature (°C) |
N/R |
| Reflow Solder Time (Sec) |
N/R |
| Number of Reflow Cycle |
N/R |
| Standard |
N/R |
| Maximum Wave Temperature (°C) |
N/R |
| Wave Solder Time (Sec) |
N/R |
| Lead Finish(Plating) |
N/R |
| Under Plating Material |
N/R |
| Terminal Base Material |
N/R |
| Number of Wave Cycles |
N/R |
|
|
PACKAGING INFO
|
| Packaging |
Bag |
| Packaging Document |
Link to Datasheet |
|
|
