| CATALOG |
634-015-274-992 COUNTRY OF ORIGIN
|
634-015-274-992 PARAMETRIC INFO
|
634-015-274-992 PACKAGE INFO
|
634-015-274-992 MANUFACTURING INFO
|
634-015-274-992 PACKAGING INFO
|
|
COUNTRY OF ORIGIN
|
China
|
|
PARAMETRIC INFO
|
| Type |
D-Sub |
| Contact Gender |
SKT |
| Number of Contacts |
15 |
| Termination Method |
Solder |
| Number of Ports |
1 |
| Maximum Current Rating (A) |
1 |
| Gender |
RCP |
| Number of Rows |
3 |
| Housing Material |
Nylon 6T |
| Shell Material |
Steel |
| Shell Plating |
Nickel |
| Shell Size |
E |
| Contact Material |
Phosphor Bronze |
| Contact Plating |
Gold Over Nickel |
| Insulation Resistance (MOhm) |
1000 |
| Maximum Contact Resistance (mOhm) |
30 |
| Operating Temperature (°C) |
-40 to 230 |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
230 |
| Less Contact |
No |
|
|
PACKAGE INFO
|
| Terminal Pitch (mm) |
1.52 |
| Body Orientation |
Right Angle |
| Mounting |
Through Hole |
| Number of Terminals |
15 |
| Product Length (mm) |
30.78 |
| Product Depth (mm) |
N/A |
| Product Height (mm) |
12.44 |
|
|
MANUFACTURING INFO
|
| MSL |
N/R |
| Maximum Reflow Temperature (°C) |
N/R |
| Reflow Solder Time (Sec) |
N/R |
| Maximum Wave Temperature (°C) |
265 |
| Wave Solder Time (Sec) |
10 |
| Wave Temp. Source |
Link to Datasheet |
| Lead Finish(Plating) |
Sn |
| Under Plating Material |
Ni |
| Terminal Base Material |
Phosphor-Bronze |
|
|
PACKAGING INFO
|
| Packaging |
Tray |
| Quantity Of Packaging |
54 |
|
|
