| Logic Family |
AC |
| Process Technology |
CMOS |
| Logic Function |
Inverter |
| Number of Elements per Chip |
6 |
| Minimum High Level Output Voltage (V) |
2.9 |
| Minimum Operating Supply Voltage (V) |
2 |
| Maximum Low Level Output Voltage (V) |
0.1 |
| Maximum Operating Supply Voltage (V) |
6 |
| Typical Operating Supply Voltage (V) |
2.5|3.3|5 |
| Minimum Storage Temperature (°C) |
-65 |
| Maximum Storage Temperature (°C) |
150 |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
85 |
| Maximum Propagation Delay Time @ Maximum CL (ns) |
9@3.3V|7@5V |
| Absolute Propagation Delay Time (ns) |
10 |
| Propagation Delay Test Condition (pF) |
50 |
| Maximum High Level Output Current (mA) |
-24 |
| Maximum Low Level Output Current (mA) |
24 |
| Maximum Quiescent Current (uA) |
2 |
