| Type |
Analog Switch |
| Number of Channels per Chip |
1 |
| Switch Architecture |
SPST |
| Polarity |
Non-Inverting |
| Maximum On Resistance Range (Ohm) |
150 to 250 |
| Configuration |
Single SPST |
| Number of Inputs per Chip |
1 |
| Function |
General |
| Latch-Up Proof |
Yes |
| Number of Outputs per Chip |
1 |
| Logic Family |
LVC |
| Chip Enable Signals |
Yes |
| Maximum On Resistance (Ohm) |
195@1.95V |
| Maximum Propagation Delay Bus to Bus (ns) |
0.2(Typ)@5.5V|0.3(Typ)@3.6V|0.4(Typ)@2.7V|0.8(Typ)@1.95V |
| Maximum Turn-On Time (ns) |
5.3(Typ)@1.95V |
| Maximum Turn-Off Time (ns) |
4.2(Typ)@1.95V |
| Maximum Power Dissipation (mW) |
250 |
| Input Signal Type |
Single |
| Output Signal Type |
Single |
| Maximum Low Level Output Current (mA) |
50 |
| Maximum High Level Output Current (mA) |
50 |
| Maximum Frequency (25°C) @ Vcc (MHz) |
500(Typ)@1.65V|500(Typ)@4.5V |
| Switch Control Logic |
Active High |
| Switch Normal Position |
NO |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
125 |
| Maximum Storage Temperature (°C) |
150 |
| Minimum Storage Temperature (°C) |
-65 |
| Power Supply Type |
Single |
| Minimum Single Supply Voltage (V) |
1.65 |
| Typical Single Supply Voltage (V) |
3|5 |
| Maximum Single Supply Voltage (V) |
5.5 |
| Typical Supply Current (mA) |
0.0001@3.3V |
| Maximum Supply Current (mA) |
0.2@5.5V@-40C to 125C |
