| Type |
Key Switch |
| Pole Throw Configuration |
SPST |
| Switch Configuration |
N.O. |
| Maximum Current Rating (A) |
0.1@16VAC 16VDC |
| Maximum AC Voltage Rating (V) |
16 |
| Maximum DC Voltage Rating (V) |
16 |
| Mechanical Life (Cycles) |
100000 |
| Actuator Style |
Round Button |
| Operating Force (N) |
2.94 |
| Ground Terminal |
No |
| Contact Material |
Gold |
| Base Material |
Thermoplastic |
| Base/Housing Material |
Thermoplastic/N/A |
| Dielectric Strength |
250VAC |
| Maximum Contact Resistance (mOhm) |
100 |
| Minimum Insulation Resistance (MOhm) |
100 |
| Actuator Length (mm) |
1.65 |
| Maximum Operating Temperature (°C) |
125 |
| Minimum Operating Temperature (°C) |
-55 |
| IP Rating |
IP67 |
| Body Length (mm) |
5 |
| Body Depth (mm) |
5 |
| Body Height (mm) |
2.17 |
| Terminal Length (mm) |
4 |
| Number of Rows |
2 |
| Row Spacing (mm) |
5 |
| Operating Temperature (°C) |
-55 to 125 |
| Maximum Storage Temperature (°C) |
125 |
| Minimum Storage Temperature (°C) |
-55 |
