827914-3 COUNTRY OF ORIGIN
|
827914-3 PARAMETRIC INFO
|
827914-3 PACKAGE INFO
|
827914-3 MANUFACTURING INFO
|
827914-3 PACKAGING INFO
|
|
COUNTRY OF ORIGIN
|
Switzerland
|
Germany
|
|
PARAMETRIC INFO
|
| Type |
Shunt |
| Gender |
F |
| Number of Contacts |
2 |
| Maximum Current Rating (A) |
3/Contact |
| Housing Material |
Glass Filled Polyamide 6/6 |
| Housing Color |
Black |
| Contact Material |
Beryllium Copper |
| Contact Plating |
Tin Over Nickel |
| Number of Rows |
1 |
| Maximum Contact Resistance (mOhm) |
15 |
| Operating Temperature (°C) |
-40 to 85 |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
85 |
| Mating Cycle (Cycles) |
20 |
|
|
PACKAGE INFO
|
| Terminal Pitch (mm) |
2.54 |
| Body Orientation |
Straight |
| Mounting |
N/A |
| Product Length (mm) |
N/A |
| Product Depth (mm) |
N/A |
| Product Height (mm) |
6 |
|
|
MANUFACTURING INFO
|
| MSL |
N/R |
| Maximum Reflow Temperature (°C) |
N/R |
| Reflow Solder Time (Sec) |
N/R |
| Reflow Temp. Source |
Link to Datasheet |
| Maximum Wave Temperature (°C) |
N/R |
| Wave Solder Time (Sec) |
N/R |
| Wave Temp. Source |
Link to Datasheet |
| Lead Finish(Plating) |
N/A |
| Under Plating Material |
N/A |
| Terminal Base Material |
BeCu |
|
|
PACKAGING INFO
|
| Packaging |
Box |
| Quantity Of Packaging |
1400 |
|
|
