| 953118-1 COUNTRY OF ORIGIN |
953118-1 PARAMETRIC INFO
|
953118-1 PACKAGE INFO
|
953118-1 MANUFACTURING INFO
|
953118-1 PACKAGING INFO
|
|
| COUNTRY OF ORIGIN |
| Czechia |
| Germany |
| France |
| Belgium |
|
PARAMETRIC INFO
|
| Type |
Micro Quadlok Interconnection |
| Gender |
HDR |
| Number of Contacts |
40 |
| Termination Method |
Solder |
| Maximum Voltage Rating |
12VDC |
| Housing Material |
Polybutylene Terephthalate |
| Housing Color |
Black |
| Contact Material |
Bronze Powder |
| Contact Plating |
Tin |
| Number of Rows |
4 |
| Operating Temperature (°C) |
-40 to 85 |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
85 |
|
|
PACKAGE INFO
|
| Terminal Pitch (mm) |
2.54 |
| Body Orientation |
Straight |
| Mounting |
Through Hole |
| Product Length (mm) |
31.2 |
| Product Depth (mm) |
25.9 |
| Product Height (mm) |
21.5 |
|
|
MANUFACTURING INFO
|
| MSL |
N/R |
| Maximum Reflow Temperature (°C) |
N/R |
| Reflow Solder Time (Sec) |
N/R |
| Maximum Wave Temperature (°C) |
240 |
| Wave Solder Time (Sec) |
N/A |
| Wave Temp. Source |
Link to Datasheet |
| Lead Finish(Plating) |
N/A |
| Under Plating Material |
N/A |
| Terminal Base Material |
N/A |
|
|
PACKAGING INFO
|
| Packaging |
Tray |
| Quantity Of Packaging |
432 |
|
