A4982SLPTR-T Allegro MicroSystems IC MOTOR DRIVER PAR 24TSSOP

Type	Motor Driver
Maximum Operating Current (mA)	8
Minimum Operating Temperature (°C)	-20
Maximum Operating Temperature (°C)	85
Minimum Operating Supply Voltage (V)	8
Maximum Operating Supply Voltage (V)	35
Minimum Storage Temperature (°C)	-55
Maximum Storage Temperature (°C)	150
Motor Type	Stepper Motor

Supplier Package	TSSOP EP
Basic Package Type	Lead-Frame SMT
Pin Count	24
Lead Shape	Gull-wing
PCB	24
Tab	N/R
Pin Pitch (mm)	0.65
Package Length (mm)	7.8
Package Width (mm)	4.4
Package Height (mm)	1.05(Max)
Package Diameter (mm)	N/R
Seated Plane Height (mm)	1.2(Max)
Mounting	Surface Mount
Package Material	Plastic
Package Description	Thin Shrink Small Outline Package, Exposed Pad
Package Family Name	SO
Jedec	N/A

MSL	2
Maximum Reflow Temperature (°C)	260
Reflow Solder Time (Sec)	20 to 40
Number of Reflow Cycle	3
Standard	J-STD-020C
Reflow Temp. Source	Link to Datasheet
Maximum Wave Temperature (°C)	N/R
Wave Solder Time (Sec)	N/R
Lead Finish(Plating)	Matte Sn annealed
Under Plating Material	N/A
Terminal Base Material	Cu Alloy
Number of Wave Cycles	N/R
