| Converter Type |
Resolver to Digital |
| Digital Interface Type |
Serial |
| Resolution (bit) |
12 |
| Accuracy (arcmin) |
±10.6 |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
85 |
| Supplier Temperature Grade |
Industrial |
| Input Signal Type |
Differential |
| Velocity Output |
Yes |
| Maximum Input Voltage |
2.2Vrms |
| Maximum Common Mode Input Voltage |
0.1Vp |
| Maximum Input Frequency (kHz) |
20 |
| Typical Reference Frequency (kHz) |
20(Max) |
| Typical Voltage Reference |
2V |
| Typical Tracking Rate (r/s) |
500(Min) |
| Power Supply Type |
Dual |
| Minimum Dual Supply Voltage (V) |
±4.75 |
| Typical Dual Supply Voltage (V) |
±5 |
| Maximum Dual Supply Voltage (V) |
±5.25 |
| Maximum Supply Current (mA) |
10 |
| Module/IC Classification |
IC |
