| Manufacturer Type |
Zero Drift Amplifier |
| Type |
Auto Zero/Chopper |
| Rail to Rail |
Rail to Rail Input/Output |
| Minimum Single Supply Voltage (V) |
2.7 |
| Number of Channels per Chip |
4 |
| Process Technology |
CMOS |
| Minimum PSRR (dB) |
120 |
| Typical Single Supply Voltage (V) |
3 |
| Maximum Single Supply Voltage (V) |
5 |
| Output Type |
CMOS |
| Maximum Quiescent Current (mA) |
3.9@5V |
| Typical Gain Bandwidth Product (MHz) |
1.5 |
| Maximum Input Offset Voltage (mV) |
0.005@5V |
| Maximum Input Offset Current (uA) |
0.00007@5V |
| Maximum Operating Supply Voltage (V) |
5 |
| Maximum Input Bias Current (uA) |
0.00005@5V |
| Minimum CMRR (dB) |
120 |
| Maximum Supply Voltage Range (V) |
<5.5 |
| Minimum CMRR Range (dB) |
>=115 |
| Typical Voltage Gain (dB) |
145 |
| Typical Slew Rate (V/us) |
0.4@5V |
| Typical Output Current (mA) |
30@5V |
| Typical Input Noise Voltage Density (nV/rtHz) |
51@5V |
| Typical Noninverting Input Current Noise Density (pA/rtHz) |
0.002@5V |
| Typical Input Bias Current (uA) |
0.00001@5V |
| Shut Down Support |
No |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
125 |
| Supplier Temperature Grade |
Automotive |
| Minimum Storage Temperature (°C) |
-65 |
| Maximum Storage Temperature (°C) |
150 |
| Power Supply Type |
Single |
