| Manufacturer Type |
Low Noise Amplifier |
| Type |
Low Noise Amplifier |
| Rail to Rail |
Rail to Rail Input/Output |
| Minimum Single Supply Voltage (V) |
2.7 |
| Number of Channels per Chip |
2 |
| Process Technology |
CMOS |
| Minimum PSRR (dB) |
80 |
| Typical Single Supply Voltage (V) |
3|5 |
| Maximum Single Supply Voltage (V) |
5.5 |
| Output Type |
CMOS |
| Maximum Quiescent Current (mA) |
2.4@5V |
| Typical Gain Bandwidth Product (MHz) |
10 |
| Maximum Input Offset Voltage (mV) |
0.3@5V |
| Maximum Input Offset Current (uA) |
0.0000005@5V |
| Maximum Input Voltage Range (V) |
0 to 5 |
| Maximum Operating Supply Voltage (V) |
5.5 |
| Maximum Input Bias Current (uA) |
0.000001@5V |
| Minimum CMRR (dB) |
85 |
| Maximum Supply Voltage Range (V) |
5.5 to 6 |
| Minimum CMRR Range (dB) |
85 to 90 |
| Typical Voltage Gain (dB) |
120 |
| Typical Slew Rate (V/us) |
5@5V |
| Typical Input Offset Current (uA) |
0.0000001@5V |
| Typical Settling Time (ns) |
1000 |
| Typical Output Current (mA) |
80@5V |
| Typical Input Noise Voltage Density (nV/rtHz) |
8@5V |
| Typical Noninverting Input Current Noise Density (pA/rtHz) |
0.01@5V |
| Typical Input Bias Current (uA) |
0.0000002@5V |
| Shut Down Support |
No |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
125 |
| Supplier Temperature Grade |
Extended Industrial |
| Minimum Storage Temperature (°C) |
-65 |
| Maximum Storage Temperature (°C) |
150 |
| Power Supply Type |
Single |
| Typical High Level Output Voltage (V) |
4.98 |
| Typical Low Level Output Voltage (V) |
0.17 |
| Input Offset Voltage Drift (uV/°C) |
4.5 |
