| Manufacturer Type |
Precision Amplifier |
| Type |
Precision Amplifier |
| Number of Channels per Chip |
2 |
| Process Technology |
XFCB |
| Minimum PSRR (dB) |
100 |
| Minimum Dual Supply Voltage (V) |
±5 |
| Typical Gain Bandwidth Product (MHz) |
25 |
| Maximum Input Offset Voltage (mV) |
0.25@±5V |
| Typical Dual Supply Voltage (V) |
±9|±12 |
| Maximum Input Offset Current (uA) |
0.00001@±5V |
| Maximum Dual Supply Voltage (V) |
±13 |
| Maximum Input Voltage Range (V) |
-2 to 3 |
| Maximum Operating Supply Voltage (V) |
±13 |
| Maximum Input Bias Current (uA) |
0.00001@±5V |
| Minimum CMRR (dB) |
90 |
| Maximum Supply Voltage Range (V) |
17 to 30 |
| Minimum CMRR Range (dB) |
90 to 95 |
| Typical Voltage Gain (dB) |
105.11 |
| Typical Slew Rate (V/us) |
50@±5V |
| Typical Settling Time (ns) |
350 |
| Typical Output Current (mA) |
30@±5V |
| Typical Input Noise Voltage Density (nV/rtHz) |
6@±5V |
| Typical Noninverting Input Current Noise Density (pA/rtHz) |
0.005@±5V |
| Typical Input Bias Current (uA) |
0.000002@±5V |
| Shut Down Support |
No |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
125 |
| Supplier Temperature Grade |
Extended Industrial |
| Minimum Storage Temperature (°C) |
-65 |
| Maximum Storage Temperature (°C) |
150 |
| Power Supply Type |
Dual |
| Maximum Supply Current (mA) |
6@±5V |
| Typical High Level Output Voltage (V) |
4 |
| Typical Low Level Output Voltage (V) |
-4 |
| Input Offset Voltage Drift (uV/°C) |
3.5 |
