| Manufacturer Type |
Precision Amplifier |
| Type |
Precision Amplifier |
| Rail to Rail |
Rail to Rail Output |
| Number of Channels per Chip |
2 |
| Minimum PSRR (dB) |
125 |
| Typical Input Resistance (Ohm) |
1T |
| Maximum Quiescent Current (mA) |
0.5@±15V |
| Minimum Dual Supply Voltage (V) |
±2.5 |
| Typical Gain Bandwidth Product (MHz) |
0.56 |
| Maximum Input Offset Voltage (mV) |
0.125@±15V |
| Typical Dual Supply Voltage (V) |
±3|±5|±9|±12 |
| Maximum Input Offset Current (uA) |
0.0002@±15V |
| Maximum Dual Supply Voltage (V) |
±15 |
| Maximum Input Voltage Range (V) |
-13.8 to 13.8 |
| Maximum Operating Supply Voltage (V) |
±15 |
| Maximum Input Bias Current (uA) |
0.0002@±15V |
| Minimum CMRR (dB) |
125 |
| Maximum Supply Voltage Range (V) |
30 to 32 |
| Minimum CMRR Range (dB) |
>=115 |
| Typical Voltage Gain (dB) |
137 |
| Typical Slew Rate (V/us) |
0.48@±15V |
| Typical Input Offset Current (uA) |
0.000035@±15V |
| Typical Input Noise Voltage Density (nV/rtHz) |
11@±15V |
| Typical Noninverting Input Current Noise Density (pA/rtHz) |
0.15@±15V |
| Typical Input Bias Current (uA) |
0.000045@±15V |
| Shut Down Support |
No |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
125 |
| Supplier Temperature Grade |
Extended Industrial |
| Minimum Storage Temperature (°C) |
-65 |
| Maximum Storage Temperature (°C) |
150 |
| Power Supply Type |
Dual |
| Typical Output Resistance (Ohm) |
1.5 |
| Typical High Level Output Voltage (V) |
14.89 |
| Typical Low Level Output Voltage (V) |
-14.89 |
| Input Offset Voltage Drift (uV/°C) |
1.2 |
