| Manufacturer Type |
Low Noise Amplifier |
| Number of Channels per Chip |
1 |
| Typical Power Gain (dB) |
26.5@20000MHz |
| Typical Noise Figure (dB) |
2@20000MHz |
| Typical Output Intercept Point (dBm) |
28@20000MHz |
| Maximum Power Dissipation (mW) |
1140 |
| Maximum Operating Frequency (MHz) |
20000 |
| Typical Output Power (dBm) |
15@20000MHz |
| Typical Output Power Range (dBm) |
15 to 20 |
| Maximum Input Return Loss (dB) |
16.5(Typ)@20000MHz |
| Maximum Output Return Loss (dB) |
10.5(Typ)@20000MHz |
| Power Supply Type |
Single |
| Minimum Single Supply Voltage (V) |
3 |
| Typical Single Supply Voltage (V) |
5 |
| Maximum Single Supply Voltage (V) |
5.5 |
| Maximum Operating Supply Voltage (V) |
5.5 |
| Maximum Supply Current (mA) |
90(Typ) |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
85 |
