| Data Bus Width (bit) |
32 |
| Family Name |
SAM E54 |
| Device Core |
ARM Cortex M4F |
| Instruction Set Architecture |
RISC |
| Maximum Clock Rate (MHz) |
120 |
| Program Memory Type |
Flash |
| Program Memory Size |
1MB |
| RAM Size |
256KB |
| DMA Channels |
32 |
| Ethernet Interface Type |
MII/RMII |
| Ethernet Speed |
10Mbps/100Mbps |
| Memory Management Unit |
No |
| Maximum CPU Frequency (MHz) |
120 |
| Number of Programmable I/Os |
99 |
| Number of Timers |
13 |
| ADC Channels |
16/16 |
| ADC Resolution (bit) |
12/12 |
| DAC Channels |
2 |
| Core Architecture |
ARM |
| Number of ADCs |
Dual |
| DAC Resolution (bit) |
12 |
| Number of DACs |
Single |
| PWM |
1 |
| Watchdog |
1 |
| Analog Comparators |
4 |
| Parallel Master Port |
No |
| Real Time Clock |
No |
| Special Features |
CAN Controller |
| Interface Type |
CAN/Ethernet/I2S/SPI/USB |
| Programmability |
Yes |
| SPI |
1 |
| I2C |
0 |
| I2S |
1 |
| UART |
0 |
| USART |
0 |
| CAN |
1 |
| USB |
1 |
| Ethernet |
1 |
| Minimum Operating Supply Voltage (V) |
1.71 |
| Typical Operating Supply Voltage (V) |
3.3 |
| Maximum Operating Supply Voltage (V) |
3.63 |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
85 |
| Temperature Flag |
Opr |
| Supplier Temperature Grade |
Industrial |
| Operating Supply Voltage (V) |
3.3 |
| Maximum Storage Temperature (°C) |
150 |
| Minimum Storage Temperature (°C) |
-60 |
