| Data Bus Width (bit) |
8|16 |
| Family Name |
XMEGA |
| Device Core |
AVR |
| Instruction Set Architecture |
RISC |
| Maximum Clock Rate (MHz) |
32 |
| Program Memory Type |
Flash |
| Program Memory Size |
64KB |
| RAM Size |
4KB |
| Maximum Expanded Memory Size |
16MB |
| Trace Hardware |
JTAG |
| Encryption Standard |
AES |
| DMA Channels |
4 |
| EEPROM |
4KB |
| Direct Memory Access |
Yes |
| Floating Point Unit |
No |
| Bluetooth |
No |
| Wi-Fi |
No |
| Multiply Accumulate |
No |
| Input Capture Channels |
4 |
| Output Compare Channels |
4 |
| Internal/External Clock Type |
Internal/External |
| Touch Sensing Interface |
No |
| Power On Reset |
No |
| Memory Protection Unit |
No |
| Temperature Sensor |
Yes |
| DDR |
No |
| Memory Management Unit |
No |
| Integrated Development Environment |
No |
| Super Scalar |
No |
| External Bus Interface |
No |
| Maximum CPU Frequency (MHz) |
32 |
| Number of Programmable I/Os |
34 |
| Number of Timers |
5 |
| ADC Channels |
12 |
| ADC Resolution (bit) |
12 |
| DAC Channels |
2 |
| Core Architecture |
AVR |
| Number of ADCs |
Single |
| DAC Resolution (bit) |
12 |
| Number of DACs |
Single |
| PWM |
1 |
| Watchdog |
1 |
| Analog Comparators |
2 |
| Parallel Master Port |
No |
| Real Time Clock |
Yes |
| Timers Resolution (bit) |
16/16/16/16/16 |
| Interface Type |
SPI/USART/USB |
| Programmability |
Yes |
| SPI |
2 |
| I2C |
0 |
| I2S |
0 |
| UART |
0 |
| USART |
5 |
| CAN |
0 |
| USB |
1 |
| Ethernet |
0 |
| Minimum Operating Supply Voltage (V) |
1.6 |
| Typical Operating Supply Voltage (V) |
1.8|2.5|3.3 |
| Maximum Operating Supply Voltage (V) |
3.6 |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
85 |
| Temperature Flag |
Opr |
| Operating Supply Voltage (V) |
1.8|2.5|3.3 |
| Maximum Storage Temperature (°C) |
150 |
| Minimum Storage Temperature (°C) |
-65 |
