| PARAMETRIC INFO |
| Type |
Housing |
| Gender |
RCP |
| Number of Contacts |
3 |
| Termination Method |
Crimp |
| Maximum Current Rating (A) |
5/1 |
| Maximum Voltage Rating |
30VDC|30VAC |
| Housing Material |
Polybutylene Terephthalate |
| Housing Color |
Gray |
| Number of Rows |
1 |
| Wire Size (AWG) |
22-30 |
| Insulation Resistance (MOhm) |
100 |
| Operating Temperature (°C) |
-25 to 85 |
| Minimum Operating Temperature (°C) |
-25 |
| Maximum Operating Temperature (°C) |
85 |
|
| |
| PACKAGE INFO |
| Terminal Pitch (mm) |
1.5 |
| Body Orientation |
Straight |
| Mounting |
Cable Mount |
| Product Height (mm) |
5.2 |
|
| |
| MANUFACTURING INFO |
| MSL |
N/R |
| Maximum Reflow Temperature (°C) |
N/R |
| Reflow Solder Time (Sec) |
N/R |
| Number of Reflow Cycle |
N/R |
| Standard |
N/R |
| Reflow Temp. Source |
Link to Datasheet |
| Maximum Wave Temperature (°C) |
N/R |
| Wave Solder Time (Sec) |
N/R |
| Wave Temp. Source |
Link to Datasheet |
| Lead Finish(Plating) |
N/R |
| Under Plating Material |
N/R |
| Terminal Base Material |
N/R |
| Number of Wave Cycles |
N/R |
|
| |
| PACKAGING INFO |
| Packaging Document |
Link to Datasheet |
|
|
