| Type |
Small Signal Switching Diode |
| Configuration |
Dual Common Cathode |
| Peak Reverse Repetitive Voltage (V) |
250 |
| Maximum DC Reverse Voltage (V) |
200 |
| Maximum Continuous Forward Current (A) |
0.4 |
| Maximum Power Dissipation (mW) |
350 |
| Speed |
Ultra Fast Recovery Rectifier |
| Maximum Junction Ambient Thermal Resistance |
357°C/W |
| Peak Forward Voltage (V) |
1.25@0.2A |
| Maximum RMS Reverse Voltage (V) |
141 |
| Peak Non-Repetitive Surge Current (A) |
9 |
| Peak Reverse Current (uA) |
0.1 |
| Peak Reverse Recovery Time (ns) |
50 |
| Operating Junction Temperature (°C) |
-55 to 150 |
| Minimum Storage Temperature (°C) |
-55 |
| Maximum Storage Temperature (°C) |
150 |
| Maximum Diode Capacitance (pF) |
5 |
| Minimum Operating Temperature (°C) |
-55 |
| Maximum Operating Temperature (°C) |
150 |
| Supplier Temperature Grade |
Commercial |
