BTT60101ERAXUMA1 COUNTRY OF ORIGIN
|
BTT60101ERAXUMA1 PARAMETRIC INFO
|
BTT60101ERAXUMA1 PACKAGE INFO
|
BTT60101ERAXUMA1 PACKAGING INFO
|
BTT60101ERAXUMA1 APPLICATION
|
|
COUNTRY OF ORIGIN
|
Malaysia
|
Austria
|
|
PARAMETRIC INFO
|
| Number of Outputs |
1 |
| Number of Inputs |
1 |
| Minimum Input Voltage (V) |
8 |
| Maximum Input Voltage (V) |
36 |
| Maximum Output Current (A) |
9(Typ) |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
150 |
| Switch On Resistance (mOhm) |
10 |
| Maximum Power Dissipation (mW) |
1600 |
| Minimum Storage Temperature (°C) |
-55 |
| Maximum Storage Temperature (°C) |
150 |
|
|
PACKAGE INFO
|
| Supplier Package |
TDSO EP |
| Pin Count |
14 |
| PCB |
14 |
| Tab |
N/R |
| Package Length (mm) |
8.65 |
| Package Width (mm) |
3.9 |
| Package Height (mm) |
0.95 |
| Package Diameter (mm) |
N/R |
| Mounting |
Surface Mount |
| Package Family Name |
SO |
| Package Outline |
Link to Datasheet |
|
|
PACKAGING INFO
|
| Packaging |
Tape and Reel |
| Quantity Of Packaging |
3000 |
|
|
APPLICATION
|
• Suitable for resistive, inductive and capacitive loads
|
• Replaces electromechanical relays, fuses and discrete circuits
|
• Most suitable for loads with high inrush current, such as lamps
|
• Suitable for 12 V and 24 V truck and transportation system
|
|
