| Logic Family |
CD4000 |
| Process Technology |
CMOS |
| Logic Function |
Monostable Multivibrator |
| Number of Elements per Chip |
2 |
| Minimum Operating Supply Voltage (V) |
3 |
| Maximum Operating Supply Voltage (V) |
18 |
| Typical Operating Supply Voltage (V) |
3.3|5|9|12|15 |
| Minimum Operating Temperature (°C) |
-55 |
| Maximum Operating Temperature (°C) |
125 |
| Supplier Temperature Grade |
Military |
| Maximum High Level Output Current (mA) |
-4.2(Min) |
| Maximum Low Level Output Current (mA) |
4.2(Min) |
| Maximum Propagation Delay Time @ Maximum CL (ns) |
600@5V|300@10V|220@15V |
| Maximum Quiescent Current (mA) |
0.1 |
| Absolute Propagation Delay Time (ns) |
600 |
