DCK-3R3E224U-E COUNTRY OF ORIGIN
|
DCK-3R3E224U-E LIFECYCLE
|
DCK-3R3E224U-E PARAMETRIC INFO
|
DCK-3R3E224U-E PACKAGE INFO
|
DCK-3R3E224U-E MANUFACTURING INFO
|
|
COUNTRY OF ORIGIN
|
Japan
|
|
LIFECYCLE
|
Obsolete
Sep 30,2022
|
|
PARAMETRIC INFO
|
| Capacitance Value |
0.22F |
| Voltage |
3.3VDC |
| Tolerance |
-20% to 80% |
| Lifetime (h) |
1000 |
| Maximum Operating Temperature (°C) |
60 |
| Construction |
Stacked Coin |
| Operating Temperature (°C) |
-10 to 60 |
| Minimum Operating Temperature (°C) |
-10 |
| DC Rated Voltage (VDC) |
3.3 |
| Negative Capacitance Tolerance (%) |
-20 |
| Positive Capacitance Tolerance (%) |
80 |
| Tradename |
DYNACAP™ |
| Polarity |
Polar |
| Package Region |
World Wide |
| Fixed/Variable |
Fixed |
|
|
PACKAGE INFO
|
| Package/Case |
N/A |
| Mounting |
Surface Mount |
| Termination Style |
N/R |
| Terminal Pitch (mm) |
N/R |
| Product Length (mm) |
N/R |
| Product Depth (mm) |
N/R |
| Product Height (mm) |
2.1 |
| Product Diameter (mm) |
6.8 |
| Seated Plane Height (mm) |
N/R |
| Product Weight (g) |
N/A |
| Number of Terminals |
2 |
| Size (mm) |
6.8 X 2.1 |
|
|
MANUFACTURING INFO
|
| MSL |
N/R |
| Maximum Reflow Temperature (°C) |
N/A |
| Reflow Solder Time (Sec) |
N/A |
| Reflow Temp. Source |
Link to Datasheet |
| Maximum Wave Temperature (°C) |
N/R |
| Wave Solder Time (Sec) |
N/R |
| Lead Finish(Plating) |
Sn |
| Under Plating Material |
N/A |
| Terminal Base Material |
Cu |
|
|
|
