| Family Name |
dSPIC33 |
| Data Bus Width (bit) |
16 |
| Device Core |
dsPIC |
| Instruction Set Architecture |
CISC |
| Maximum Clock Rate (MHz) |
100 |
| Program Memory Type |
Flash |
| Program Memory Size |
256KB |
| RAM Size |
24KB |
| Maximum CPU Frequency (MHz) |
100 |
| GPIO |
39 |
| Number of Timers |
1 |
| ADC Channels |
19/19/19 |
| ADC Resolution (bit) |
12/12/12 |
| Core Architecture |
PIC |
| Number of ADCs |
3 |
| Number of DACs |
3 |
| DAC Resolution (bit) |
12/12/12 |
| Watchdog |
1 |
| Analog Comparators |
3 |
| Parallel Master Port |
Yes |
| Interface Type |
CAN/I2C/SPI/UART |
| Programmability |
Yes |
| SPI |
3 |
| I2C |
3 |
| I2S |
0 |
| UART |
3 |
| USART |
0 |
| CAN |
1 |
| USB |
0 |
| Ethernet |
0 |
| Minimum Operating Supply Voltage (V) |
3 |
| Typical Operating Supply Voltage (V) |
3.3 |
| Maximum Operating Supply Voltage (V) |
3.6 |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
85 |
| Temperature Flag |
Opr |
| Supplier Temperature Grade |
Industrial |
| Operating Supply Voltage (V) |
3.3 |
| Maximum Storage Temperature (°C) |
150 |
| Minimum Storage Temperature (°C) |
-65 |
