| Data Bus Width (bit) |
16 |
| Family Name |
dsPIC33F |
| Device Core |
dsPIC |
| Instruction Set Architecture |
RISC |
| Maximum Clock Rate (MHz) |
40 |
| Program Memory Type |
Flash |
| Program Memory Size |
256KB |
| RAM Size |
30KB |
| Maximum Expanded Memory Size |
12MB |
| DMA Channels |
8 |
| Maximum CPU Frequency (MHz) |
40 |
| Number of Programmable I/Os |
85 |
| Number of Timers |
9 |
| ADC Channels |
24/24 |
| ADC Resolution (bit) |
10/12 |
| Core Architecture |
dsPIC |
| Number of ADCs |
Dual |
| PWM |
8 |
| Watchdog |
1 |
| Special Features |
CAN Controller |
| Interface Type |
CAN/I2C/SPI/UART |
| Programmability |
Yes |
| SPI |
2 |
| I2C |
2 |
| I2S |
0 |
| UART |
2 |
| USART |
0 |
| CAN |
2 |
| USB |
0 |
| Ethernet |
0 |
| Minimum Operating Supply Voltage (V) |
3 |
| Typical Operating Supply Voltage (V) |
3.3 |
| Maximum Operating Supply Voltage (V) |
3.6 |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
125 |
| Temperature Flag |
Opr |
| Supplier Temperature Grade |
Extended |
| Operating Supply Voltage (V) |
3.3 |
| Maximum Storage Temperature (°C) |
160 |
| Minimum Storage Temperature (°C) |
-65 |
