| DTM06-12SA COUNTRY OF ORIGIN |
DTM06-12SA PARAMETRIC INFO
|
DTM06-12SA PACKAGE INFO
|
DTM06-12SA MANUFACTURING INFO
|
DTM06-12SA PACKAGING INFO
|
DTM06-12SA EACD MODELS
|
|
| COUNTRY OF ORIGIN |
| Switzerland |
| Korea (Republic of) |
| Germany |
| China |
| United States of America |
| Mexico |
| United Kingdom of Great Britain and Northern Ireland |
|
PARAMETRIC INFO
|
| Type |
Housing |
| Gender |
PL |
| Number of Contacts |
12 |
| Termination Method |
Crimp |
| Maximum Current Rating (A) |
7.5/Contact |
| Maximum Voltage Rating |
250VDC |
| Housing Material |
Glass Filled Polyamide 6/6 |
| Housing Color |
Gray |
| Number of Rows |
2 |
| Wire Size (AWG) |
16-22 |
| IP Rating |
IP68/IP6K9K |
| Operating Temperature (°C) |
-55 to 125 |
| Minimum Operating Temperature (°C) |
-55 |
| Maximum Operating Temperature (°C) |
125 |
|
|
PACKAGE INFO
|
| Terminal Pitch (mm) |
4.19 |
| Body Orientation |
Straight |
| Mounting |
Cable Mount |
| Product Length (mm) |
40.01 |
| Product Depth (mm) |
43.69 |
| Product Height (mm) |
20.22 |
|
|
MANUFACTURING INFO
|
| MSL |
N/R |
| Maximum Reflow Temperature (°C) |
N/R |
| Reflow Solder Time (Sec) |
N/R |
| Number of Reflow Cycle |
N/R |
| Maximum Wave Temperature (°C) |
N/R |
| Wave Solder Time (Sec) |
N/R |
| Lead Finish(Plating) |
N/R |
| Under Plating Material |
N/R |
| Terminal Base Material |
N/R |
| Shelf Life Period |
N/R |
| Under Plating Porosity Free |
N/R |
| Number of Wave Cycles |
N/R |
|
|
PACKAGING INFO
|
| Packaging |
Box |
| Quantity Of Packaging |
600 |
|
|
ECAD MODELS
|
|
|
