| Device Logic Units |
12060 |
| Device Logic Cells |
12060 |
| Maximum Number of User I/Os |
249 |
| Number of I/O Banks |
4 |
| Device Number of DLLs/PLLs |
2 |
| Maximum LVDS Data Rate (Mbps) |
640 |
| Tradename |
Cyclone |
| Maximum I/O Performance |
640Mbps |
| RAM Bits (Kbit) |
234 |
| Total Number of Block RAM |
52 |
| Program Memory Type |
SRAM |
| Series name |
Cyclone® |
| Process Technology |
130nm |
| Speed Grade |
7 |
| Differential I/O Standards Supported |
LVDS|PCI |
| Single-Ended I/O Standards Supported |
LVTTL|LVCMOS|SSTL-2|SSTL-3 |
| External Memory Interface |
DDR SDRAM|FCRAM |
| Copy Protection |
yes |
| Shift Registers |
Utilize Memory |
| Supported IP Core |
Video LVDS SerDes Transmitter / Receiver|RLDRAM II Controller Core|IFI Advanced CAN IP |
| Programmability |
no |
| Supported IP Core Manufacture |
Microtronix Inc/CAST, Inc/Northwest Logic, Inc/IFI |
| In-System Programmability |
yes |
| Reprogrammability Support |
no |
| Maximum Internal Frequency (MHz) |
320.1 |
| Number of Global Clocks |
8 |
| Maximum Operating Supply Voltage (V) |
1.575 |
| I/O Voltage (V) |
1.5|1.8|2.5|3.3 |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
100 |
| Temperature Flag |
June |
| Supplier Temperature Rating |
Industrial |
| Digital Control Impedance |
no |
| Minimum Operating Supply Voltage (V) |
1.425 |
| Typical Operating Supply Voltage (V) |
1.5 |
| Tolerant Configuration Interface Voltage (V) |
1.5|1.8|2.5|3.3 |
