| Device Logic Cells |
60440 |
| Device Logic Units |
60440 |
| Maximum Number of User I/Os |
718 |
| Number of I/O Banks |
8 |
| Device Number of DLLs/PLLs |
12 |
| Number of Multipliers |
144 (18x18) |
| Number of Regional Clocks |
32 |
| Tradename |
Stratix |
| Maximum I/O Performance |
1Gbps |
| RAM Bits (Kbit) |
2484.6 |
| Total Number of Block RAM |
2+255+329 |
| Program Memory Type |
SRAM |
| Family Name |
Stratix® II |
| Process Technology |
90nm |
| Speed Grade |
4 |
| Dedicated DSP |
36 |
| Differential I/O Standards Supported |
LVPECL|LVDS |
| Single-Ended I/O Standards Supported |
LVTTL|CMOS|SSTL|HSTL |
| Giga Multiply Accumulates per Second |
37.8 |
| External Memory Interface |
DDR SDRAM|DDR2 SDRAM|RLDRAM II|QDRII+SRAM |
| Mega Multiply Accumulates per second |
37800 |
| Copy Protection |
Yes |
| Shift Registers |
Utilize Memory |
| Supported IP Core Manufacture |
Altera/CAST, Inc/Barco Silex/Mobiveil, Inc/Eureka Technology Inc/PLDA |
| In-System Programmability |
Yes |
| Reprogrammability Support |
No |
| Maximum Internal Frequency (MHz) |
711.24 |
| Number of Global Clocks |
16 |
| Maximum Operating Supply Voltage (V) |
1.25 |
| I/O Voltage (V) |
1.2|1.5|1.8|2.5|3.3 |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
100 |
| Temperature Flag |
Jun |
| Supplier Temperature Grade |
Industrial |
| Digital Control Impedance |
No |
| Minimum Operating Supply Voltage (V) |
1.15 |
| Typical Operating Supply Voltage (V) |
1.2 |
| Tolerant Configuration Interface Voltage (V) |
1.5|1.8|2.5|3.3 |
| Maximum Storage Temperature (°C) |
150 |
| Minimum Storage Temperature (°C) |
-65 |
