| Device Logic Units |
15408 |
| Device Logic Cells |
15408 |
| Maximum Number of User I/Os |
346 |
| Number of I/O Banks |
8 |
| Device Number of DLLs/PLLs |
4 |
| Number of Multipliers |
56 (18x18) |
| Maximum LVDS Data Rate (Mbps) |
875 |
| Tradename |
Cyclone |
| RAM Bits (Kbit) |
504 |
| Total Number of Block RAM |
56 |
| Program Memory Type |
SRAM |
| Family Name |
Cyclone® III |
| Process Technology |
65nm |
| Speed Grade |
8 |
| Differential I/O Standards Supported |
LVPECL|LVDS|HSTL-18|HSTL-15|HSTL-12|SSTL-2|SSTL-18|RSDS |
| Single-Ended I/O Standards Supported |
LVTTL|LVCMOS|PCI|PCI-X|SSTL|HSTL |
| JTAG Support (-) |
Yes |
| External Memory Interface |
DDR2 SDRAM|QDRII+SRAM |
| Copy Protection |
Yes |
| Supported IP Core |
Viterbi Compiler, Low-Speed/Hybrid Serial Decoder|V1 ColdFire|SpeedView Enabled JPEG Encoder (SVE-JPEG-E)|10 Gigabit Ethernet MAC| 32/64-bit PCI-X bus Master/Target interface Core, 66/100/133Mhz |
| Programmability |
No |
| Supported IP Core Manufacture |
Altera/Freescale/CAST, Inc/MorethanIP/PLDA |
| In-System Programmability |
No |
| Number of Look-up Table Input |
4 |
| Reprogrammability Support |
No |
| Maximum Internal Frequency (MHz) |
402 |
| Number of Global Clocks |
20 |
| Maximum Operating Supply Voltage (V) |
1.25 |
| I/O Voltage (V) |
1.2|1.5|1.8|2.5|3.3 |
| Minimum Operating Temperature (°C) |
0 |
| Maximum Operating Temperature (°C) |
85 |
| Temperature Flag |
Jun |
| Supplier Temperature Grade |
Commercial |
| Digital Control Impedance |
No |
| Minimum Operating Supply Voltage (V) |
1.15 |
| Typical Operating Supply Voltage (V) |
1.2 |
| Maximum Storage Temperature (°C) |
150 |
| Minimum Storage Temperature (°C) |
-65 |
