| Channel Type |
N |
| Channel Mode |
Enhancement |
| Configuration |
Single |
| Maximum Drain Source Voltage (V) |
80 |
| Maximum Continuous Drain Current (A) |
90 |
| Maximum Absolute Continuous Drain Current (A) |
90 |
| Maximum Gate Source Voltage (V) |
±20 |
| Maximum Drain Source Resistance (mOhm) |
7.9@10V |
| Typical Gate Charge @ Vgs (nC) |
36@10V |
| Typical Gate Charge @ 10V (nC) |
36 |
| Maximum Power Dissipation (mW) |
150000 |
| Category |
Power MOSFET |
| Typical Input Capacitance @ Vds (pF) |
2530@40V |
| Typical Turn-On Delay Time (ns) |
13 |
| Typical Turn-Off Delay Time (ns) |
22 |
| Typical Fall Time (ns) |
9 |
| Typical Rise Time (ns) |
34 |
| Number of Elements per Chip |
1 |
| Minimum Storage Temperature (°C) |
-55 |
| Maximum Storage Temperature (°C) |
175 |
| Minimum Operating Temperature (°C) |
-55 |
| Maximum Operating Temperature (°C) |
175 |
