| Manufacturer Type |
MMIC Amplifier |
| Number of Channels per Chip |
1 |
| Typical Power Gain (dB) |
14.5@6000MHz |
| Typical Noise Figure (dB) |
5@6000MHz |
| Typical Output 1dB Compressed Power @ Bias Conditions (dBm) |
13 |
| Typical 3rd Order Output Intercept Point @ Bias Conditions (dBm) |
24 |
| Typical Output Intercept Point (dBm) |
24@6000MHz |
| Maximum Reverse Isolation (dB) |
20(Typ)@6000MHz |
| Maximum Power Dissipation (mW) |
340 |
| Maximum Operating Frequency (MHz) |
6000 |
| Typical Output Power (dBm) |
13@6000MHz |
| Typical Output Power Range (dBm) |
10 to 15 |
| Maximum Input Return Loss (dB) |
8(Typ)@6000MHz |
| Maximum Output Return Loss (dB) |
8(Typ)@6000MHz |
| Power Supply Type |
Single |
| Maximum Single Supply Voltage (V) |
7 |
| Maximum Operating Supply Voltage (V) |
7 |
| Maximum Supply Current (mA) |
74@5V |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
85 |
