| Manufacturer Type |
MMIC Amplifier |
| Number of Channels per Chip |
1 |
| Typical Power Gain (dB) |
16@4000MHz |
| Typical Noise Figure (dB) |
4.5@4000MHz |
| Process Technology |
InGaP HBT |
| Operational Bias Conditions |
5V/82mA |
| Typical Output 1dB Compressed Power @ Bias Conditions (dBm) |
18 |
| Typical 3rd Order Output Intercept Point @ Bias Conditions (dBm) |
29 |
| Typical Output Intercept Point (dBm) |
29@4000MHz |
| Maximum Reverse Isolation (dB) |
23(Typ)@4000MHz |
| Maximum Power Dissipation (mW) |
510 |
| Maximum Operating Frequency (MHz) |
4000 |
| Typical Output Power (dBm) |
18@4000MHz |
| Typical Output Power Range (dBm) |
15 to 20 |
| Maximum Input Return Loss (dB) |
10(Typ)@4000MHz |
| Maximum Output Return Loss (dB) |
8(Typ)@4000MHz |
| Power Supply Type |
Single |
| Typical Single Supply Voltage (V) |
5 |
| Maximum Single Supply Voltage (V) |
5.5 |
| Maximum Operating Supply Voltage (V) |
5.5 |
| Maximum Supply Current (mA) |
102@5V |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
85 |
| Maximum Storage Temperature (°C) |
150 |
| Minimum Storage Temperature (°C) |
-65 |
