| Manufacturer Type |
MMIC Amplifier |
| Number of Channels per Chip |
1 |
| Typical Power Gain (dB) |
17.5@40000MHz |
| Typical Noise Figure (dB) |
7@40000MHz |
| Typical Output 1dB Compressed Power @ Bias Conditions (dBm) |
21 |
| Typical 3rd Order Output Intercept Point @ Bias Conditions (dBm) |
26 |
| Typical Output Intercept Point (dBm) |
26@40000MHz |
| Minimum Operating Frequency (MHz) |
18000 |
| Maximum Power Dissipation (mW) |
1575 |
| Maximum Operating Frequency (MHz) |
40000 |
| Typical Output Power (dBm) |
21@40000MHz |
| Typical Output Power Range (dBm) |
20 to 30 |
| Maximum Input Return Loss (dB) |
7(Typ)@40000MHz |
| Maximum Output Return Loss (dB) |
7(Typ)@40000MHz |
| Power Supply Type |
Quad |
| Typical Dual Supply Voltage (V) |
5 |
| Maximum Dual Supply Voltage (V) |
5.5 |
| Maximum Operating Supply Voltage (V) |
5.5 |
| Maximum Supply Current (mA) |
280(Typ)@5V |
| Minimum Operating Temperature (°C) |
-55 |
| Maximum Operating Temperature (°C) |
85 |
