• Small-size with low profile
|
• Waterproof construction
|
• Push/pull lock
|
• Light weight
|
• Clamp structure
|
• Easy mating operation
|
• Mis-insertion prevention
|
• Mating mark
|
|
| CATALOG |
HR30-6R-6S(71) COUNTRY OF ORIGIN
|
HR30-6R-6S(71) PARAMETRIC INFO
|
HR30-6R-6S(71) PACKAGE INFO
|
HR30-6R-6S(71) MANUFACTURING INFO
|
HR30-6R-6S(71) PACKAGING INFO
|
|
COUNTRY OF ORIGIN
|
Japan
|
|
PARAMETRIC INFO
|
| Type |
Circular |
| Contact Gender |
SKT |
| Number of Contacts |
6 |
| Termination Method |
Solder |
| Number of Ports |
1 |
| Gender |
RCP |
| Contacts Classification |
6Signal |
| Maximum Voltage Rating |
100VAC |
| Maximum Current Rating (A) |
2 |
| Maximum Contact Resistance (mOhm) |
15 |
| Wire Size (AWG) |
26-30 |
| Insulation Resistance (MOhm) |
1000 |
| IP Rating |
IP67 |
| Contact Material |
Brass|Phosphor Bronze |
| Contact Plating |
Gold |
| Strain Relief |
No |
| Less Contact |
No |
| Operating Temperature (°C) |
-25 to 85 |
| Minimum Operating Temperature (°C) |
-25 |
| Maximum Operating Temperature (°C) |
85 |
| Mating Cycle (Cycles) |
1000 |
| Minimum Storage Temperature (°C) |
-25 |
| Maximum Storage Temperature (°C) |
85 |
|
|
PACKAGE INFO
|
| Body Orientation |
Straight |
| Mounting |
Panel Mount |
| Number of Terminals |
6 |
| Product Length (mm) |
18.4 |
| Product Depth (mm) |
N/A |
| Product Height (mm) |
N/A |
| Product Diameter (mm) |
12 |
|
|
MANUFACTURING INFO
|
| MSL |
N/R |
| Maximum Reflow Temperature (°C) |
N/R |
| Reflow Solder Time (Sec) |
N/R |
| Maximum Wave Temperature (°C) |
N/A |
| Wave Solder Time (Sec) |
N/A |
| Wave Temp. Source |
Link to Datasheet |
| Lead Finish(Plating) |
N/A |
| Under Plating Material |
N/A |
| Terminal Base Material |
Phosphor-Bronze|Brass |
|
|
| PACKAGING INFO |
|
|
| |
