| Channel Type |
N |
| Channel Mode |
Enhancement |
| Configuration |
Single |
| Maximum Drain Source Voltage (V) |
600 |
| Maximum Continuous Drain Current (A) |
48 |
| Maximum Gate Source Voltage (V) |
20 |
| Maximum Drain Source Resistance (mOhm) |
60@10V |
| Typical Gate Charge @ Vgs (nC) |
67@10V |
| Typical Gate Charge @ 10V (nC) |
67 |
| Maximum Power Dissipation (mW) |
164000 |
| Category |
Power MOSFET |
| Maximum Junction Ambient Thermal Resistance (°C/W) |
62 |
| Typical Input Capacitance @ Vds (pF) |
2895@400V |
| Typical Turn-On Delay Time (ns) |
23 |
| Typical Turn-Off Delay Time (ns) |
79 |
| Typical Fall Time (ns) |
4 |
| Typical Rise Time (ns) |
12 |
| Maximum Gate Threshold Voltage (V) |
4 |
| Number of Elements per Chip |
1 |
| Minimum Storage Temperature (°C) |
-55 |
| Maximum Storage Temperature (°C) |
150 |
| Minimum Operating Temperature (°C) |
-55 |
| Maximum Operating Temperature (°C) |
150 |
