| Style |
Encapsulated |
| Type |
Regulated |
| Number of Outputs |
1 |
| Typical AC Input Voltage (V) |
110|230 |
| Output Voltage (V) |
24 |
| Input/Output Type |
AC/DC |
| Maximum Output Power (W) |
60 |
| Maximum Output Current (A) |
2.5 |
| Minimum Operating Temperature (°C) |
-30 |
| Cooling Type |
Convection |
| Derating |
50%@50°C to 70°C |
| Fan |
No |
| Heat Sink |
No |
| I2C Interface |
No |
| O-Ring Protection |
No |
| Warranty |
3Year |
| Maximum Operating Temperature (°C) |
70 |
| Minimum DC Input Voltage (V) |
120 |
| Maximum DC Input Voltage (V) |
430 |
| Line Regulation |
0.5% |
| Minimum AC Input Voltage (V) |
85 |
| Maximum AC Input Voltage (V) |
305 |
| Power Supply Color |
Black |
| Output Connector Type |
PC Pins |
| Input Connector Type |
PC Pins |
| Power Indicator |
No |
| Output Type |
Fixed |
| Load Regulation |
0.5% |
| Efficiency (%) |
90(Typ) |
| Maximum Input Current (A) |
1.8(Typ) |
| Input Frequency (Hz) |
47 to 440 |
| Minimum Isolation Voltage |
3000VAC |
| Tolerance (%) |
±2.5 |
| Ripple and Noise |
150mV(Max) |
| Minimum Storage Temperature (°C) |
-40 |
| Maximum Storage Temperature (°C) |
85 |
| Configurable |
No |
| Medical Application |
No |
