| Manufacturer Type |
Low Power Amplifier |
| Type |
Low Power Amplifier |
| Rail to Rail |
Rail to Rail Input/Output |
| Minimum Single Supply Voltage (V) |
1.8 |
| Number of Channels per Chip |
4 |
| Minimum PSRR (dB) |
78 |
| Typical Single Supply Voltage (V) |
3|5|9|12|15|18 |
| Typical Input Resistance (Ohm) |
104M |
| Maximum Single Supply Voltage (V) |
24 |
| Minimum Dual Supply Voltage (V) |
±0.9 |
| Typical Gain Bandwidth Product (MHz) |
10 |
| Maximum Input Offset Voltage (mV) |
6@5V |
| Typical Dual Supply Voltage (V) |
±3|±5|±9 |
| Maximum Input Offset Current (uA) |
0.03@5V |
| Maximum Dual Supply Voltage (V) |
±12 |
| Maximum Operating Supply Voltage (V) |
±12|24 |
| Maximum Input Bias Current (uA) |
0.18@5V |
| Minimum CMRR (dB) |
60 |
| Maximum Supply Voltage Range (V) |
17 to 30 |
| Minimum CMRR Range (dB) |
60 to 65 |
| Typical Voltage Gain (dB) |
100 |
| Typical Slew Rate (V/us) |
14@5V |
| Minimum Slew Rate (V/us) |
8@5V |
| Typical Input Offset Current (uA) |
0.0034@5V |
| Typical Output Current (mA) |
25(Max) |
| Typical Input Noise Voltage Density (nV/rtHz) |
27@5V |
| Typical Noninverting Input Current Noise Density (pA/rtHz) |
0.18@5V |
| Typical Input Bias Current (uA) |
0.11@5V |
| Shut Down Support |
No |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
85 |
| Supplier Temperature Grade |
Industrial |
| Minimum Storage Temperature (°C) |
-65 |
| Maximum Storage Temperature (°C) |
150 |
| Power Supply Type |
Single|Dual |
| Maximum Supply Current (mA) |
1.6@5V |
| Input Offset Voltage Drift (uV/°C) |
5(Typ) |
