| Rail to Rail |
Rail to Rail Output |
| Manufacturer Type |
Low Voltage Comparator |
| Number of Channels per Chip |
1 |
| Output Type |
Open Collector |
| Maximum Input Offset Voltage (mV) |
7@5V |
| Maximum Input Bias Current (uA) |
0.25@5V |
| Typical Voltage Gain (dB) |
93.98 |
| Typical Voltage Gain Range (dB) |
90 to 110 |
| Strobe Capability |
No |
| Typical Output Current (mA) |
84@5V |
| Typical Input Offset Current (uA) |
0.002@5V |
| Maximum Input Offset Current (uA) |
0.05@5V |
| Maximum Propagation Delay Time (ns) |
600(Typ) |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
125 |
| Minimum Storage Temperature (°C) |
-65 |
| Maximum Storage Temperature (°C) |
150 |
| Power Supply Type |
Single |
| Integrated Voltage Reference |
No |
| Maximum Test Temperature (°C) |
125 |
| Minimum Test Temperature (°C) |
-40 |
| Maximum Operating Supply Voltage (V) |
5.5 |
| Integrated OP Amp |
No |
| Minimum Single Supply Voltage (V) |
2.7 |
| Typical Single Supply Voltage (V) |
3|5 |
| Maximum Single Supply Voltage (V) |
5.5 |
| Maximum Supply Current (mA) |
0.12@5V |
